Primary Model

Two-Bedroom Apartment

A modern 2-bedroom apartment designed for the 50—100 plot —— the most popular residential lot size. Features a fully fenced compound with security house, 2-car parking, landscaped walkways, and elegant finishing.

Plot Size
50 — 100 ft
Bedrooms
2
Bathrooms
2
Parking
2 Cars
Style
Modern
Technical Overview

Complete Project Specifications

Comprehensive technical details for architects, engineers, and construction professionals.

📐 Plot & Building Dimensions

  • Plot Size: 50ft — 100ft (15.24m — 30.48m) = 5,000 sq ft
  • Building Footprint: 33'-4" — 26'-8" (10.16m — 8.13m) = 889 sq ft
  • Total Built-Up Area: 889 sq ft (82.6 m²)
  • Front Setback: 6'-0" (1.83m) minimum
  • Side Setbacks: 3'-0" (0.91m) each side
  • Rear Setback: 10'-0" (3.05m)
  • Plot Coverage: 17.8% (well within 40% max)

🚪 Doors Schedule

  • D1 —— Master Bedroom: 3'-0" — 7'-0" flush timber door
  • D2 —— En-Suite Bath: 2'-6" — 7'-0" waterproof door
  • D3 —— Bedroom 2: 3'-0" — 7'-0" flush timber door
  • D4 —— Bathroom 2: 2'-6" — 7'-0" waterproof door
  • D5 —— Main Entry: 3'-6" — 7'-0" security steel door
  • Door Hardware: All doors with lever handles, 3 hinges each

🪟 Windows Schedule

  • W1 —— Master Bedroom: 5'-10" — 4'-0" casement (2-panel)
  • W2 —— Bedroom 2: 5'-10" — 4'-0" casement (2-panel)
  • W3 —— Living Room: 5'-0" — 4'-0" casement (vertical)
  • W4 —— Kitchen: 5'-0" — 3'-0" sliding aluminum
  • W5 —— Dining Area: 5'-0" — 4'-0" casement (vertical)
  • Glazing: 6mm clear float glass with mosquito mesh

🏠 Room Areas Breakdown

  • Master Bedroom: 14'-0" — 12'-0" = 168 sq ft (15.6 m²)
  • En-Suite Bathroom: 7'-6" — 5'-4" = 40 sq ft (3.7 m²)
  • Bedroom 2: 14'-0" — 12'-0" = 168 sq ft (15.6 m²)
  • Living Room: 14'-0" — 9'-4" = 131 sq ft (12.2 m²)
  • Kitchen: 14'-0" — 5'-4" = 75 sq ft (7.0 m²)
  • Bathroom 2: 5'-6" — 5'-4" = 29 sq ft (2.7 m²)
  • Dining Area: 14'-0" — 6'-0" = 84 sq ft (7.8 m²)
  • Corridor: 6'-0" — 13'-0" = 78 sq ft (7.2 m²)
HD Architectural Blueprint

Floor Plan & Compound Layout

Interactive HD blueprint —— use zoom and pan controls to explore the detailed floor plan, compound arrangement, and structural elements. All drawings conform to international standards with grid axes, dimension chains, and professional annotations.

Floor Plan —— 2-Bedroom Apartment
FLOOR PLAN —— TWO-BEDROOM APARTMENT ArchVision Studio · Drawing No. AV-2BR-FP-001 · Rev. B Scale 1:100 All dimensions in feet-inches 0 5' 10' 15' 20' A B C D E 1 2 3 4 MASTER BEDROOM 14'-0" — 12'-0" (168 sq ft) FFL +0.00 WARDROBE W1 D1 EN-SUITE 7'-6" — 5'-4" SHOWER D2 BEDROOM 2 14'-0" — 12'-0" (168 sq ft) FFL +0.00 DESK WARDROBE W2 D3 C O R R I D O R LIVING ROOM 14'-0" — 9'-4" W3 KITCHEN 14'-0" — 5'-4" REF BATH 2 5'-6" — 5'-4" D4 DINING AREA 14'-0" — 6'-0" W5 MAIN DOOR D5 —— 3'-6" — 7'-0" 33'-4" 26'-8" 15'-4" 18'-0" N TRUE NORTH LEGEND Structural Wall (230mm) Window Door Door Swing Wet Area (Tiled) A A
COMPOUND LAYOUT —— 50 — 100 PLOT Scale: 1:150 · Drawing No. AV-2BR-CL-001 · Perimeter Block Wall Fence · Sliding Gate PERIMETER FENCE —— 225mm Block Wall, 8ft Height, Razor Wire Top MAIN BUILDING Two-Bedroom Apartment 33'-4" — 26'-8" · FFL +0.45m SLIDING GATE 10'-0" Wide · Motorized Steel DRIVEWAY Interlocking Concrete Pavers CAR 1 2.5m — 5.0m CAR 2 2.5m — 5.0m SECURITY HOUSE 8' — 6' · 1-Room WALKWAY —— 600mm Wide WALKWAY —— 600mm Wide LAWN LAWN 6'-0" Front Setback 8'-0" Side 50'-0" (Plot Width) 100'-0" (Plot Depth) N DRAIN LINE →
STRUCTURAL PLAN —— FOUNDATION & COLUMN LAYOUT Reinforced Concrete Frame · Drawing No. AV-2BR-SP-001 · Scale 1:100 Concrete Grade: C25/30 Steel Grade: B500B A B C D E 1 2 3 C1 C2 C3 C4 C5 C6 C7 C8 C9 C10 C11 C12 C13 C14 C15 4.57m 3.35m 3.35m 4.57m 5.79m 7.62m COLUMN SECTION DETAIL (Typ.) Size: 230mm — 230mm Main bars: 4 No. Y16 Stirrups: R8 @ 200mm c/c Cover: 25mm all sides BEAM SECTION DETAIL (Typ.) Size: 230mm — 450mm Top: 2 No. Y16 Bottom: 3 No. Y16 Stirrups: R8 @ 150mm c/c STRIP FOUNDATION DETAIL Width: 600mm Depth: 900mm below GL Concrete: C25/30 Blinding: 50mm thick
ROOF STRUCTURE —— HIP ROOF ELEVATION & PLAN Aluminum Long-Span Roofing Sheets · Drawing No. AV-2BR-RF-001 · Scale 1:80 Pitch: 22° Eave Overhang: 450mm ROOF —— SIDE ELEVATION Wall Plate 100—50mm RIDGE BEAM —— 200mm — 50mm Hardwood Purlins 50—75mm Purlins 50—75mm FASCIA BOARD —— 225mm — 25mm Treated Timber 22° Rafter 50—150mm @ 600mm c/c 3.05m ROOF —— PLAN VIEW Ridge Line GUTTER —— 150mm Half-Round PVC DP DP 11.6m (Overall Roof Width inc. Overhang)
Specifications

Room-by-Room Breakdown

🛏️ Master Bedroom

  • Dimensions: 14'-0" — 12'-0" (168 sq ft)
  • En-suite bathroom with shower
  • Built-in wardrobe alcove
  • Window: 6'-0" casement (north-facing)
  • Porcelain tile flooring

🛏️ Bedroom 2

  • Dimensions: 14'-0" — 12'-0" (168 sq ft)
  • Access to shared bathroom
  • Wardrobe space included
  • Window: 6'-0" casement (north-facing)
  • Porcelain tile flooring

🛋️ Living Room

  • Dimensions: 14'-0" — 9'-4" (131 sq ft)
  • Open connection to dining area
  • Large window with garden view
  • Accent wall feature
  • Polished porcelain flooring

🍳 Kitchen & Dining

  • Kitchen: 14'-0" — 5'-4" (75 sq ft)
  • Dining: 14'-0" — 6'-0" (84 sq ft)
  • L-shaped counter with granite top
  • Space for 6-seater dining table
  • Anti-slip ceramic tiles
HD Photography

Real Luxury Home Photography

HD photography from world-class luxury residences comparable to Banana Island (Lagos), Vancouver, Stockholm, and Auckland —— showcasing the lifestyle our designs deliver.

two-bedroom exterior - luxury modern home Exterior — Modern Architecture
two-bedroom interior - contemporary living Interior — Luxury Living Space
two-bedroom aerial view Aerial — Property Overview

🏛️ Exterior Render Details

  • Architectural Style: Contemporary Minimalism inspired by Tadao Ando & John Pawson
  • Primary Material: Exposed board-formed concrete (fair-faced finish)
  • Secondary Material: Horizontal timber cladding (Accoya/Thermowood)
  • Glazing System: Floor-to-ceiling curtain wall with aluminum mullions
  • Cantilevered Volume: Upper floor extends 1.2m beyond ground floor
  • Roof Type: Flat roof with hidden drainage, 3° slope
  • Entry Feature: Floating concrete canopy with concealed LED lighting
  • Landscape: Japanese-inspired minimalism with sculptural trees & reflection pool
  • Lighting Design: Recessed pathway bollards, uplighting on trees
  • Time of Day: Golden hour (sunset) demonstrating warm interior glow

🗺️ Aerial View Details

  • Site Planning: L-shaped building optimizing solar orientation
  • Green Roof Area: 120 sq ft sedum/wildflower intensive system
  • Skylight Integration: 4— linear skylights (8" — 130") for natural daylighting
  • Rooftop Terrace: 100 sq ft outdoor living with weather-resistant furniture
  • Infinity Pool: 70 sq ft negative-edge pool with deck surround
  • Paver Surface: Premium interlocking concrete (herringbone pattern)
  • Parking Configuration: 2 covered bays (2.5m — 5.0m each)
  • Automated Gate: 3m sliding steel gate with intercom system
  • Landscape Elements: Circular hedge sculpture, linear hedgerows, feature trees
  • Sustainable Features: Rainwater harvesting, permeable paving, native planting

🛋️ Interior Design Specifications

  • Interior Style: Luxury Minimalism inspired by John Pawson & Tadao Ando
  • Ceiling Height: 3.0m (9'-10") floor-to-ceiling
  • Flooring: Premium oak herringbone parquet (engineered)
  • Feature Wall: Vertical timber slat paneling (walnut finish)
  • Glazing: Floor-to-ceiling windows with slim aluminum frames
  • Sofa: B&B Italia-inspired modular sectional (full-grain leather)
  • Accent Chair: Eames-style lounge in premium blue upholstery
  • Coffee Table: Carrara marble top with blackened steel legs
  • Pendant Lighting: Sculptural brass cluster pendants (dimmable LED)
  • Artwork: Large-format abstract canvas in gallery frame
  • Indoor Plants: Fiddle leaf fig in ceramic planter

✨ Material & Finish Schedule

  • External Walls: 230mm concrete block + 50mm insulation + render
  • Internal Walls: 150mm block with gypsum plaster finish
  • Ceiling Finish: White matte emulsion (RAL 9010)
  • Wall Finish: Off-white matte emulsion (RAL 9002)
  • Wet Areas: 600—600mm porcelain tiles (rectified edge)
  • Kitchen Counter: 20mm quartz composite (white veined)
  • Bathroom Fixtures: Wall-hung WC, floating vanity, rain shower
  • Door Finish: Oak veneer with concealed hinges
  • Window Frames: Powder-coated aluminum (anthracite grey)
  • Hardware: Brushed brass handles and hooks throughout
Plan vs. Reality

Blueprint to Completion

Drag the slider to compare the architectural plan with the completed project visualization.

Blueprint Completed
Bed 1 Bed 2 Living / Kitchen / Dining HD Architectural Blueprint —— 2 BEDROOM APT
COMPLETED PROJECT —— MODERN FINISHING
Interior

Interior Layout Suggestions

🛋️

Living Space

Minimalist modern furniture, open layout with accent wall in warm taupe. Recessed LED ceiling lights.

🍳

Kitchen

White handleless cabinets, black granite countertop, under-cabinet LED strip lighting.

🛏️

Master Bedroom

King-size bed, built-in wardrobe, earth-tone palette. Blackout curtains with sheer overlay.

🚿

Bathrooms

Walk-in shower (en-suite), wall-hung vanity, large-format porcelain tiles in grey.

🌿

Landscape

Interlocking pavers for driveway, ornamental grasses, flowering shrubs along walkways.

🔒

Security

Gatehouse with direct view of entrance, intercom system, CCTV mounting points at corners.

Download Complete Plans

Get the full HD Architectural Blueprint, structural plan, and material specifications for the Two-Bedroom Apartment project.
